Product Description
High Quality Molybdenum & Molybdenum Alloy Strip/Foil
Application
Molybdenum Foil/strip is widely used in reflection shield, cover plate applied in the sapphire growth furnace, reflection shield heating tape, connecting pieces applied in vacuum furnace, sputtering target applied in plasma coating film and high temperature resistance boat.
When temperature is beyond 1200 degree centigrade, pure molybdenum will completely recrystallizate quickly. To improve the property, engineers added other elements to molybdenum to increase the recrystallization temperature. Studies suggested that the complete recrystallization temperature of molybdenum with doped chemical reached 1800 degree centigrade.
All the sizes can be manufactured based on customer's requirements
We can produce many varieties of tungsten and molybdenum parts for single crystal growing process with its best properties.
Specification
|
Place of Origin |
Shaanxi, China |
|
Brand Name |
SYMT |
|
Model |
Mo1, Mo2 |
|
Shape |
strip/foil |
|
Purity |
99.95% Min |
|
Density |
10.2g/m3 |
|
Melting Point |
2617℃ |
|
Standard |
GB,ASTM |
|
Dimension |
According to your requirements |
|
Quality |
ISO9001:2008 |
|
Application |
producing electric light source parts, producing sputtering Targets |
|
MOQ |
1Kg |
|
Surface |
can be in shiny, bright or as-rolled condition |
2. Specifications of High Pure Molybdenum Plate
|
Thickness |
Thickness Tolerance |
Width |
Width |
Length |
Length |
|
0.10~0.30 |
±0.01 |
≤350 |
±2 |
≤1300 |
±5 |
|
0.31~2.00 |
±0.05 |
≤600 |
±5 |
≤1300 |
±5 |
|
2.01~3.00 |
±0.08 |
≤400 |
±3 |
≤1000 |
±5 |
|
3.01~4.00 |
±0.10 |
≤400 |
±3 |
≤1000 |
±5 |
3.Process
Raw material→Reduction→Metal power→Mixing→Pressing→Sintering→Forming→Heat treatment→Machining Joining Coating→Quality assurance
4.Our Testing Result
|
Our testing for Molybdenum Plates |
|||||
|
Fe |
Ni |
C |
Al |
O |
N |
|
0.004 |
0.002 |
0.0028 |
0.0005 |
0.005 |
0.002 |
|
Si |
Ca |
Mg |
Cd |
Sb |
Sn |
|
0.0013 |
< 0.001 |
< 0.0005 |
< 0.001 |
< 0.0005 |
< 0.0005 |
|
P |
Cu |
Pb |
Bi |
Mo |
|
|
< 0.001 |
< 0.0005 |
< 0.0005 |
< 0.0005 |
>99.95% |
|
5 . Packaging ans shipping
1, packaging with moisture-proof paper 2, packaging with kraft paper 3, packaging with foam plastics in all side of wooden case. 4, packing products in wooden case
6. Payment terms
Payment Terms: T/T, L/C at sight, D/A, D/P, Western Union or as your inquiry
Transportation: Shipping goods by TNT, DHL, Fedex, UPS, EMS etc.
Transport goods to Beijing or Shanghai air port by air transportation or as your requirement.
